Charnwood Bay VL Insert Woodburning Stove

• SIA Eco Design Ready
• Cleanburn Airwash Technology
• Drop down throat plate enabling the chimney to be swept through the stove
• DEFRA exempt for burning wood in smoke control area

Output – 5.0kW (range 2-7kW)

Materials – Plate steel, cast iron, ceramic glass, VLAZE vitreous enamel surround

RATED OUTPUT 5kW to room (range 2-7kW)

NET EFFICIENCY 81%

FLUE OUTLET Top 150mm (6”) dia

MAX LOG LENGTH 463mm (18”)

WEIGHT 94.3KG

MIN DISTANCE TO COMBUSTIBLES Side: 190mm Top: 350mm

A freestanding version, the Bay BX, is also available. This can either be placed directly on the hearth or on a choice of optional stands.
